Hikmicro Thunder TE25 2.0 Thermal Scope

Thunder TE25 2.0

The TE25 2.0 Thermal Image Scope has a 256 × 192 thermal detector and a 1024 × 768 OLED display, which provides clear images under harsh environment conditions like darkness, fog, smoke, dust, rain, snow, wood, camouflage, etc. With an extended operation time, the scope is mainly applied to scenarios such as hiking, hunting, searching and rescuing.

256 × 192 resolution with 12 μm sensor
1024 × 768 resolution 0.39″ OLED display
Supports image brightness and tone adjustment
Up to 10 hours of continuous operation
Replaceable and rechargeable Li-ion battery
Supports audio and recoil-activated recording
High shock resistance up to 1,000 g/0.4 ms
Detection Range: 1,200 m

Thermal Module

Image Sensor: Uncooled Focal Plane Arrays
Resolution: 256 × 192
Frame Rate: 50 Hz
Pixel Interval: 12 mm
NETD: Less than 35 mK (25°C, F# = 1.0)
Lens (Focal Length): 25 mm
Focus Knob: No
Detection Range: 1,200 m
Focusing Distance: 0.5 m
Aperture: F1.0
Magnification: 3.25 ×
Field Of View (H × V), Degrees/M @100 m: 7.03° × 5.28°/12.29 m × 9.22 m

Image Display

Display: 1024 × 768, 0.39 Inch, OLED
Palettes: Black hot, white hot, red hot, fusion
FFC (Flat Field Correction) Mode: Auto, Manual, External Correction
Exit Pupil: 6 mm
Eye Relief: 45 mm
Diopter (Range): -5 D To 5 D
Brightness Adjustment: Yes
Tone Adjustment: Cold, Warm

System

Record Video: On-Board Video Recording
Capture Snapshot: Yes
Digital Zoom: 1x, 2x, 4x, 8x
Standby Mode : Yes
Storage: Built-In EMMC (16 Gb)
PIP: Yes
DPC: Yes
Hotspot: Yes
Hot Track: Yes
Distance Measurement: Yes
Recoil-Activation Recording: Yes
Audio Recording: Yes
Recoil: 1,000 g/0.4 ms

Power Supply

Battery Type: Replaceable and Rechargeable Li-Ion Battery
Battery Operating Time: ≥ 10 h (25°C, with hotspot off)
Type-C Power Supply: 5 VDC, 2 A; Supports external power supply

General

Protection Level: IP67
Dimension: 218.7 mm × 67.14 mm × 68.04 mm
Weight: 494 g without Battery
Working Temperature: -30°C to +55°C

What’s in the box
HIKMICRO Thunder TE25 2.0 25 mm Thermal Monocular & Riflescope (19 mm)
Battery Charger
Battery x2
Type-C Cable
Quick Start Guide
Bag
Wrench
